Mkernel, our scheduler for our unikernels

A derivation of Miou for unikernels

Following this brief digression on the scheduler, it may be worth using Miou and mkernel to develop our unikernels. In this case, mkernel extends Miou to handle all I/O-related tasks with Solo5.

As mentioned, Solo5 is very minimal and offers only two devices: what is known as a network interface (which can easily be thought of as an Ethernet socket) and what is known as a block device (which can easily be thought of as a hard drive).

It is through these two types of devices that we obtain four hypercalls: that is to say, functions that interact with these devices:

1. read an Ethernet frame
2. write an Ethernet frame
3. read a page from a block device
4. write a page to a block device

This is how mkernel essentially offers two things:

1. integration of these hypercalls with the Miou scheduler
2. the ability to specify the devices required for your unikernel

Your first unikernel with mkernel

If we go back to our example with dune, we simply need to add mkernel as a dependency for our unikernel. This library, just as we explained with regard to digestif, contains C stubs, so it must be marked as a vendor library:

let () = Mkernel.(run []) @@ fun () ->
  print_endline "Hello World!"

$ unic infer -r . -x _build -x vendors > _mfetch
$ mfetch --with-dune-file
mkernel                          ok
$ dune build
$ solo5-hvt -- _build/solo5/main.exe --solo5:quiet
Hello World!

It is worth noting that the startup.c file we used to have to write is no longer needed. This is because mkernel implements it for us.

Next, unlike Miou{,_unix}.run, our Mkernel.run function takes a rather special list: the one that specifies our devices. Let’s give it a go with a block device:

let () = Mkernel.(run [ block "disk" ]) @@ fun blk () ->
  let bstr = Bstr.create (Mkernel.Block.pagesize blk) in
  Mkernel.Block.atomic_read blk ~src_off:0 bstr;
  Fmt.pr "@[<hov>%a@]" (Hxd_string.pp Hxd.default) (Bstr.to_string bstr)

When extending our code, there are several things to do:

1. We need to modify the dune file to include the new libraries bstr, hxd.core and hxd.string (for HexDump)
2. we must double-check whether adding these libraries means (or not) that some of them need to be marked as vendor libraries (we must therefore run unic infer again)
3. if we need to mark some of them as vendor libraries, we can re-run mfetch
4. Adding a device to our unikernel also requires a change to our manifest.json. There's a handy trick for this last task!

$ unic infer -r . -x _build -x vendors > _mfetch

$ mfetch
bstr                             ok
mkernel                          skipped (already vendored)

$ dune exec ./main.exe > manifest.json
$ dune build

$ echo "Hello World!" > file.txt
$ truncate -s 512 file.txt
$ solo5-hvt --block:disk=file.txt -- _build/solo5/main.exe --solo5:quiet
00000000: 4865 6c6c 6f20 576f 726c 6421 0a00 0000  Hello World!....
...

We've manipulated our first block device in our unikernel! As we can see, we assign a name to a device. This is the name that will be used when we want to run our unikernel (in this case, "disk").

Next, we associate a file called file.txt with it, which contains our "Hello World", and we display it using fmt and hxd. We’ve made a hypercall: specifically, reading a page (512 bytes) from the given block device.

We also have the complete workflow for developing a unikernel, specifically this loop involving adding dependencies, determining what needs to be vendorised using unic, and downloading the source code.

Our bootagotchi

At this stage, we're going to implement a proper unikernel using a block device. The aim is to create our own little Tamagotchi, but in the form of a unikernel: this draws a parallel with real life, as we try, at robur to look after our deployed unikernels on a daily basis. The principle is simple: to be able to save the state of our Tamagotchi to a block device.

type state =
  { boots : int32
  ; health : int32 }

let state =
  let open Bin in
  record (fun boots health -> { boots; health })
  |+ field beint32 (fun t -> t.boots)
  |+ field beint32 (fun t -> t.health)
  |> sealr

let encode blk value =
  let bstr = Bstr.create (Mkernel.Block.pagesize blk) in

  let size = Bin.size_of_value state value in
  let fn size =
    if size > Mkernel.Block.pagesize blk
    then Fmt.failwith "Impossible to encode our state into the given block \
                       device (its page is too small)" in
  Option.iter fn size;
  Mkernel.Block.atomic_read blk ~src_off:0 bstr;
  Bin.encode_bstr state value bstr (ref 0);
  Mkernel.Block.atomic_write blk ~dst_off:0 bstr

let decode blk =
  let bstr = Bstr.create (Mkernel.Block.pagesize blk) in
  Mkernel.Block.atomic_read blk ~src_off:0 bstr;
  match Bin.decode_bstr state bstr (ref 0) with
  | value -> value
  | exception _ -> Fmt.failwith "Invalid block device"

We can therefore create the core of our unikernel, which involves retrieving the state of our bootagotchi and displaying it:

let show state = match state.health with
  | n when n <= 0l ->
    Fmt.pr
{text|
  /\_/\
 ( x.x ) [Boot #%ld]
  > ^ <
|text} state.boots
  | n ->
    Fmt.pr
{text|
  /\_/\
 ( o.o ) [Boot #%ld]
  > ^ <  [Health: %ld/100]
|text} state.boots (Int32.min state.health 100l)

let run feed = Mkernel.(run [ block "bootagotchi" ]) @@ fun blk () ->
  let state = decode blk in
  let state = { state with health= Int32.add state.health feed } in
  show state;
  let next = { boots= Int32.succ state.boots
             ; health= Int32.pred state.health } in
  encode blk next

open Cmdliner

let feed =
  let doc = "Give some food to your bootagotchi." in
  Arg.(value & opt int32 0l & info [ "feed" ] ~doc)

let term =
  let open Term in
  const run $ feed

let cmd = Cmd.v (Cmd.info "bootagotchi") term

let () = Cmd.(exit @@ eval' cmd)

We're going to add our dune file to our project. This will use a trick to generate the manifest.json on the fly.

(executable
 (name main)
 (modules main)
 (link_flags :standard -cclib "-z solo5-abi=hvt")
 (libraries cmdliner mkernel fmt bin bstr)
 (foreign_stubs
  (language c)
  (names manifest)))

(rule
 (targets manifest.c)
 (deps manifest.json)
 (enabled_if
  (= %{context_name} "solo5"))
 (action
  (run solo5-elftool gen-manifest manifest.json manifest.c)))

(rule
 (targets manifest.c)
 (enabled_if
  (= %{context_name} "default"))
 (action (write-file manifest.c "")))

(rule
 (target manifest.json)
 (enabled_if
  (= %{context_name} "solo5"))
 (action
  (with-stdout-to manifest.json (run ./main.exe))))

So we can now follow our workflow and run our unikernel!

$ unic -r . -x _build -x vendors > _mfetch
$ mfetch
bin                              ok (bin, bstr)
mkernel                          ok
$ dune build
$ touch state.img
$ truncate -s 512 state.img
$ solo5-hvt --block:bootagotchi=state.img -- \
  _build/solo5/main.exe --solo5:quiet --feed 3

  /\_/\
 ( o.o ) [Boot #0]
  > ^ <  [Health: 3/100]
$ solo5-hvt --block:bootagotchi=state.img -- \
  _build/solo5/main.exe --solo5:quiet

  /\_/\
 ( o.o ) [Boot #1]
  > ^ <  [Health: 2/100]
$ solo5-hvt --block:bootagotchi=state.img -- \
  _build/solo5/main.exe --solo5:quiet

  /\_/\
 ( o.o ) [Boot #2]
  > ^ <  [Health: 1/100]
$ solo5-hvt --block:bootagotchi=state.img -- \
  _build/solo5/main.exe --solo5:quiet

  /\_/\
 ( x.x ) [Boot #3]
  > ^ <

And here's our first bootagotchi! Mkernel provides the most basic hypercalls for interacting with block devices. As such, we've also been able to develop a library such as cachet that allows us to cache page reads (as the hypercall can be quite costly) whilst also enabling us to write values of arbitrary size without being constrained by page boundaries.

A filesystem for our unikernel

Finally, a block device can be extended to support more complex operations, such as treating it as a FAT32 file system. That is why we have developed mfat, an OCaml implementation of FAT32, and here is how we could use it with mkernel:

module Blk = struct
  type t = Mkernel.Block.t

  let pagesize = Mkernel.Block.pagesize
  let read = Mkernel.Block.atomic_read
  let write = Mkernel.Block.atomic_write
end

module FAT32 = Mfat_bos.Make (Blk)

let fat32 name =
  let fn blk () =
    let v = FAT32.create blk in
    let v = Result.map_error (fun (`Msg msg) -> msg) v in
    Result.error_to_failure v in
  Mkernel.map fn [ Mkernel.block name ]

let run _ =
  Mkernel.(run [ fat32 "disk" ]) @@ fun fs () ->
  ...

Time to stop!

We're going to look at one final aspect of mkernel that comes directly from Miou: tasks. Thanks to Miou, it's possible to launch tasks and let the scheduler run them. So here we're going to have a bit of fun with time and tasks to make the unikernel a little more dynamic.

let or_raise = function Ok v -> v | Error exn -> raise exn

let rec loop time str =
  Mkernel.sleep time;
  Fmt.pr "%s%!" str;
  loop time str

let _500ms = 500_000_000
let _1s = 1_000_000_000
let _5s = 5_000_000_000

let () = Mkernel.(run []) @@ fun () ->

  let prm0 = Miou.async @@ fun () -> loop _500ms "." in
  let prm1 = Miou.async @@ fun () -> loop _1s "o" in
  let prm3 = Miou.asycn @@ fun () ->
    Mkernel.sleep _5s;
    print_endline "Bing!" in
  Miou.await_first [ prm0; prm1; prm3 ] |> or_raise

You can compile it and get a little animation!

Conclusion

We're already starting to have a bit of fun with mkernel. We now have a scheduler that can, amongst other things, handle block devices and run asynchronous tasks simultaneously. With that in mind, our brief introduction to Miou might help you take things further. The documentation for mkernel is also worth a look.

However, handling block devices is certainly not enough, which is why, in the next section, we’ll introduce you to using mnet and networking!
